Single Row Deep Groove Ball Bearing

Parts in bearing mechanical equipment

Application : Machine tool spindle & oil pump

Alternative Brands : SKF

Subseries :

Standard Deep Groove Ball Bearing
Miniature Deep Groove Ball Bearing
Flange Deep Groove Ball Bearing
Stainless Steel Deep Groove Ball Bearing
...

Specifications :

Outer Diameter (D) : 3mm-1920mm
Inner Diameter (d) : 1mm-1500mm
Overall Width (H) : 1mm-155mm
Reference Speed Ratings : 380r/min-140000r/min
Weight : 0.00003kg-500kg

Single Row Deep Groove Ball Bearing

Ceramic Deep Groove Ball Bearing

Ceramic deep groove ball bearings offer several advantages over traditional steel bearings, including high temperature and corrosion resistance, lightweight design, low friction, and increased durability. These properties make them well-suited for demanding applications where reliability, performance, and longevity are essential.

Deep Groove Ball Bearing with A Snap Ring Groove

A deep groove ball bearing with a snap ring groove is a specialized type of deep groove ball bearing that features an additional groove machined into the outer ring. This groove is designed to accommodate a snap ring, which is a retaining ring that helps secure the bearing in place axially. Deep groove ball bearings with snap ring grooves are commonly used in various industries and applications where axial retention is required, such as in gearboxes, transmissions, electric motors, and agricultural machinery.

Deep Groove Ball Bearing with Filling Slots

Deep groove ball bearings with filling slots are commonly used in industrial applications where heavy radial loads, shock loads, or misalignment may occur. They are often found in industries such as mining, construction, agriculture, and material handling. Overall, this type of bearing offers improved load-carrying capacity and performance compared to standard bearings, making them well-suited for demanding applications where reliability and durability are critical.

Flange Deep Groove Ball Bearing

Flange deep groove ball bearings are commonly used in applications where space constraints or specific mounting requirements dictate the need for a flanged design. They offer the same benefits as standard deep groove ball bearings, including high-speed capability, low friction, and versatility in handling radial and axial loads, while also providing additional features for efficient and secure installation.

Miniature Deep Groove Ball Bearing

They are characterized by their small size, high rotational speeds, and ability to handle radial and axial loads.

Stainless Steel Deep Groove Ball Bearing

Stainless steel bearings are highly resistant to corrosion from moisture, chemicals, and other environmental factors. This makes them ideal for use in industries such as food and beverage, medical equipment, marine, and outdoor applications where exposure to harsh conditions is common.

Standard Deep Groove Ball Bearing

Deep groove ball bearing with low friction coefficient, high limit speed, various size ranges and forms, it is suitable for precision instruments, low-noise motors, automobiles, motorcycles and general machinery. It is the most widely used in the machinery industry.
