LM Rail

Parts in bearing mechanical equipment

Application : Unloading systems for injection molding machines/Loaders and unloaders for lathes/CT scanners for digital dental x-rays/Sliding mechanisms of airplane seats

Alternative Brands : THK

Subseries :

SHS-N (C/LC)
SHS-N (V/LV)
SHS-N (R/LR)
SSR-N (XW)
SSR-N (XV)

Specifications :

Height : 10mm-40mm
Width : 10mm-80mm
Length : 10mm-3000mm
…

LM Rail

SHS-N (C/LC)

The SHS-N (C/LC) features flanges with threaded holes, allowing for versatile top or bottom mounting options. It is ideal for applications where mounting bolts cannot pass through the table.

SHS-N (V/LV)

The SHS-N (V/LV) is characterized by its narrower width (W) and features tapped holes. It is specifically designed for applications where space constraints limit the width available for mounting on tables or other surfaces.

SHS-N (R/LR)

The SHS-N (R/LR) has a smaller width (W), and mounting holes are tapped. SHS-N (R/LR) maintains the same height dimension of full-ball type LM Guide Model HSR-R.

SSR-N (XW)

With SSR-N (XW Type), the LM block has a smaller width (W) and tapped holes.

SSR-N (XV)

The SSR-N (XV) shares the same cross-sectional shape as the SSR-XW but features a shorter LM block length (L), designed to save space without compromising functionality.
