Bolt Mount D Series

Bolt Mount D Series

Standards

GB,ASTM/AISI,ГОСТ,BS,JIS,NF,DIN/VDEh,DIN/VDEh

Suggest Loading Capacity (kg)

16kg-350kg

Max. Loading Capacity (kg)

20kg-450kg

Weight

0.055kg-2.2kg

Structures

main ball, shell

Brand

QIBR/OEM/Neutral

Material

Carbon steel, Bearing steel, GCr15, 440 Stainless steel, 304 Stainless steel, Plastic

ODM/OEM

Support

Applications

electronics, hardware, machinery, chemical industry,transmission systems, feeding systems, processing systems, processing machinery and packaging machinery auxiliary equipment.

Bolt Mount D Series

QIBR

Model Selection

Filters

NO. Product Product Number Material Suggest Loading Capacity (kg) Max. Loading Capacity (kg) Net Weight (kg)
1 D-5HC/ D-5HC BS/CS 16 kg 20 kg 0.055 kg
2 D-5HT/ D-5HT BS/CS 16 kg 20 kg 0.120 kg
3 D-5HR/ D-5HR BS/CS 16 kg 20 kg 0.065 kg
4 D-5HB/ D-5HB BS/CS 80 kg 100 kg 0.370 kg
5 D-6HT/ D-6HT BS/CS 40 kg 50 kg 0.150 kg
6 D-6HR/ D-6HR BS/CS 60 kg 70 kg 0.210 kg
7 D-6HC/ D-6HC BS/CS 60 kg 70 kg 0.210 kg
8 D-6HN/ D-6HN BS/CS 50 kg 70 kg 0.210 kg
9 D-8HN/ D-8HN BS/CS 100 kg 150 kg 0.230 kg
10 D-12HA/ D-12HA BS/CS 250 kg 300 kg 0.890 kg
11 D-12HAR/ D-12HAR BS/CS 250 kg 300 kg 0.890 kg
12 D-16HA/ D-16HA BS/CS 350 kg 450 kg 2.200 kg
