Hex Head Bolt NJ Series

Hex Head Bolt NJ Series

Standards

GB,ASTM/AISI,ГОСТ,BS,JIS,NF,DIN/VDEh,DIN/VDEh

Main Ball Diameter (d)

12mm-45mm

Overall Width (H)

16mm-50mm

Weight

0.025kg-1.800kg

Structures

main ball, shell

Brand

QIBR/OEM/Neutral

Material

Carbon steel, Bearing steel, GCr15, 440 Stainless steel, 304 Stainless steel, Plastic

ODM/OEM

Support

Applications

electronics, hardware, machinery, chemical industry,transmission systems, feeding systems, processing systems, processing machinery and packaging machinery auxiliary equipment.

Hex Head Bolt NJ Series

QIBR

Model Selection

Filters

NO. Product Product Number Overall Width (H) Material Suggest Loading Capacity (kg) Main Ball Diameter (d) Thread specification (M)
1 NJ-12/ NJ-12 16 mm BS/CS 10 kg 12 mm M12
2 NJ-16/ NJ-16 22 mm BS/CS 20 kg 15.875 mm M8
3 NJ-25/ NJ-25 33 mm BS/CS 120 kg 25.4 mm M12
4 NJ-30/ NJ-30 40 mm BS/CS 150 kg 30.16 mm M14
5 NJ-38/ NJ-38 50 mm BS/CS 250 kg 38.1 mm M16
6 NJ-45/ NJ-45 50 mm BS/CS 350 kg 45 mm M16
