Изображения могут отличаться от продукта. Подробнее см. технические характеристики.
Стандарт
GB,ASTM/AISI,ГОСТ,BS,JIS,NF,DIN/VDEh,DIN/VDEh
Внутренний диаметр
120mm-8000mm
Наружный диаметр
280mm-8000mm
Вес
20kg-8000kg
Structures
Outer Ring, Inner Ring, Spacer, Rolling element, Seal
Бренд
Outer Ring, Inner Ring, Spacer, Rolling element, Seal
Упаковка
Standard Export Package
Материал
42CrMo, 50Mn, or Stainless Steel
Применения
Hoisting machinery, construction machinery, material handling machinery, mining machinery, metallurgical machinery, medical instruments,ships and warships, radar,wind turbine

NO. | Product | Product Number | Внутренний диаметр (di) | Наружный Диаметр (Da) | Диаметр делительной окружности шестерни | Вес | Тип шестерни |
---|---|---|---|---|---|---|---|
1 |
![]() |
XSA 14 0414 N | 344 mm | 503.3 mm | 495 mm | 32 kg | External Gear |
2 |
![]() |
XSA 14 0544 N | 474 mm | 640.3 mm | 630 mm | 44 kg | External Gear |
3 |
![]() |
XSA 14 0644 N | 574 mm | 742.3 mm | 732 mm | 52 kg | External Gear |
4 |
![]() |
XSA 14 0744 N | 674 mm | 838.1 mm | 828 mm | 59 kg | External Gear |
5 |
![]() |
XSA 14 0844 N | 774 mm | 950.1 mm | 936 mm | 71 kg | External Gear |
6 |
![]() |
XSA 14 0944 N | 874 mm | 1046.1 mm | 1032 mm | 77 kg | External Gear |
7 |
![]() |
XSA 14 1094 N | 1024 mm | 1198.1 mm | 1184 mm | 91 kg | External Gear |
Features and advantages of QIBR XSA series cross cylindrical roller slewing bearings
The QIBR XSA series cross cylindrical roller slewing bearings come with multiple significant features and advantages, playing an essential role across various industries, including:
1. QIBR XSA series cross cylindrical roller slewing bearings have excellent load capacity for manding applications
The QIBR XSA series cross cylindrical roller bearings are engineered to simultaneously handle radial and axial forces in multiple directions, excelling under heavy loads and impact conditions.
2. Superior stability and extended lifespan of QIBR XSA series cross cylindrical roller slewing bearings
The QIBR XSA series cross cylindrical roller slewing bearings are manufactured with exceptional precision and tight assembly clearance. These design features ensure superior operational stability, effectively reducing system vibrations and noise. As a result, the bearings improve overall smoothness and reliability, significantly extending their service life.
3. Tailored solutions of QIBR XSA series cross cylindrical roller bearings
QIBR offers customized services for the XSA series, allowing bearings to be designed for specific needs and to meet the unique demands of various industries and applications.
4. The efficient power transmission of QIBR XSA series cross cylindrical roller slewing bearings
With its external gear design, the QIBR XSA series bearing allows direct connection to gear drive systems, ensuring optimal power transfer efficiency. This innovation reduces reliance on additional components like chains or belts, reducing mechanical losses and lowering maintenance requirements.
Performance enhancements and solutions of QIBR XSA series cross cylindrical roller bearings
1. Improvement of bearing material characteristics
Built for harsh conditions, the QIBR XSA series cross cylindrical roller slewing bearings can be crafted from 440C stainless steel. This ensures outstanding corrosion resistance against moisture, chemicals, and other corrosive agents, maximizing their durability and service life.
2. Improvement of bearing rotational accuracy
QIBR cross cylindrical roller bearings XSA series are manufactured with state-of-the-art processing equipment and techniques, including precision heat treatment and advanced machining centers. These processes significantly improve the geometric accuracy of the inner and outer rings, reduce machining errors, and enhance the rotational accuracy and stability of the bearings.
3. Minimized maintenance and replacement
The QIBR XSA series cross cylindrical roller slewing bearings incorporate seals that prevent external contaminants from entering and reduce the risk of grease leakage. Additionally, the lubrication holes enable convenient grease application, improving bearing longevity and minimizing maintenance and replacement expenses.
4. Customized design
For different occasions, the QIBR cross cylindrical roller bearings XSA series can be tailored with individual dimensional solutions for special applications. This design not only enriches the standard of bearings but also demonstrates our commitment to providing practical guidance for manufacturers to meet the individual needs of users, making them feel catered to and valued.
In conclusion, by optimizing materials, enhancing manufacturing precision, and offering customized designs, the QIBR XSA series bearings provide exceptional performance, perfectly tailored to meet the evolving challenges of demanding applications.
Main application fields of QIBR cross cylindrical roller bearings XSA series
Machine tools
In CNC machine tools, the QIBR XSA series cross cylindrical roller slewing bearings ensure superior rotational stability, contributing to high-precision performance in rotary table systems for complex machining processes.
Medical instruments
Applied in advanced medical systems, including CT imaging machines and surgical tables, the QIBR XSA series cross cylindrical roller slewing bearings ensure stable performance and high-precision positioning, meeting the rigorous demands of healthcare environments.
Heavy equipment
In mining machinery, cranes, and construction equipment, the QIBR XSA series cross cylindrical roller slewing bearings offer superior support and anti-tilting capabilities, ensuring reliable operation under heavy and dynamic loads.
Ships and ocean engineering
The QIBR XSA series cross cylindrical roller slewing bearings are widely utilized in ship rotary equipment and offshore platforms. Their robust design ensures high load capacity and resistance to harsh marine environments, meeting the demanding requirements of maritime and offshore applications.
