Изображения могут отличаться от продукта. Подробнее см. технические характеристики.
Стандарт
GB,ASTM/AISI,ГОСТ,BS,JIS,NF,DIN/VDEh,DIN/VDEh
Внутренний диаметр
120mm-8000mm
Наружный диаметр
280mm-8000mm
Вес
20kg-8000kg
Structures
Outer Ring, Inner Ring, Spacer, Rolling element, Seal
Бренд
QIBR/OEM/Neutral
Упаковка
Standard Export Package
Материал
42CrMo, 50Mn, or Stainless Steel
Применения
Hoisting machinery, construction machinery, material handling machinery, mining machinery, metallurgical machinery, medical instruments,ships and warships, radar,wind turbine

NO. | Product | Product Number | Внутренний диаметр (d) | Наружный диаметр (D) | Диаметр дорожки качения (dm) | Вес | Тип шестерни |
---|---|---|---|---|---|---|---|
1 |
![]() |
RKS.160.14.0414 | 344 mm | 486 mm | 414 mm | 28 kg | No gear |
2 |
![]() |
RKS.160.14.0544 | 474 mm | 616 mm | 544 mm | 38 kg | No gear |
3 |
![]() |
RKS.160.14.0644 | 574 mm | 716 mm | 644 mm | 44 kg | No gear |
4 |
![]() |
RKS.160.14.0744 | 674 mm | 816 mm | 744 mm | 52 kg | No gear |
5 |
![]() |
RKS.160.14.0944 | 874 mm | 1016 mm | 944 mm | 67 kg | No gear |
6 |
![]() |
RKS.160.14.1094 | 1024 mm | 1166 mm | 1094 mm | 77 kg | No gear |
7 |
![]() |
RKS.160.16.1204 | 1119 mm | 1289 mm | 1204 mm | 124 kg | No gear |
8 |
![]() |
RKS.160.16.1314 | 1229 mm | 1399 mm | 1314 mm | 135 kg | No gear |
9 |
![]() |
RKS.160.16.1424 | 1339 mm | 1509 mm | 1424 mm | 146 kg | No gear |
10 |
![]() |
RKS.160.16.1534 | 1449 mm | 1619 mm | 1534 mm | 158 kg | No gear |
11 |
![]() |
RKS.160.16.1644 | 1536 mm | 1752 mm | 1644 mm | 215 kg | No gear |
12 |
![]() |
RKS.160.16.1754 | 1646 mm | 1862 mm | 1754 mm | 228 kg | No gear |
13 |
![]() |
RKS.160.20.1904 | 1796 mm | 2012 mm | 1904 mm | 248 kg | No gear |
14 |
![]() |
RKS.160.14.0844 | 774 mm | 916 mm | 844 mm | 60 kg | No gear |
Features and advantages of QIBR crossed cylindrical roller slewing bearing RKS 160 series
QIBR crossed cylindrical roller slewing bearing RKS 160 series has several significant features and advantages, playing a key role in various fields, mainly reflected in the following aspects:
1.QIBR crossed cylindrical roller slewing bearing RKS 160 series has high load carrying capacity
The design of QIBR crossed cylindrical roller slewing bearing RKS 160 series allows the bearing to carry radial and axial loads in multiple directions at the same time, and is suitable for withstanding heavy loads and impact loads.
2.QIBR crossed cylindrical roller slewing bearing RKS 160 series has good stability and long life
QIBR crossed cylindrical roller slewing bearing RKS 160 series has high manufacturing precision and small assembly clearance. The bearing has high working stability, reduces system vibration and noise, improves the smoothness and reliability of operation, thereby extending the service life of the bearing. .
3. The customized services of QIBR crossed cylindrical roller slew bearing RKS 160 series
QIBR crossed cylindrical roller slew bearing RKS 160 series can provide customized services and can design bearings according to specific needs to meet the special requirements and operating conditions of different industries.
The performance improvement and solutions of QIBR crossed cylindrical roller slewing bearing RKS 160 series
1. Improvement of overload capacity
QIBR Crossed Cylindrical Roller Turntable Bearing RKS 160 Series improves the bearing's load-bearing capacity in overloaded or unstable working environments by using stronger materials, improved design and processing technology, avoiding early failures caused by overload.
2. Improve rotation accuracy of the bearing
The production of QIBR Crossed Cylindrical Roller Turntable Bearing RKS 160 Series adopts advanced processing equipment and processes, such as machining centers and precision heat treatment, to improve the geometric accuracy of the inner and outer rings, reduce machining errors, and thus improve the bearing's rotation accuracy and stability.
3. Reduce the need for bearing maintenance and replacement
QIBR Crossed Cylindrical Roller Turntable Bearing RKS 160 Series is designed with seals and lubricating oil holes. The seals can prevent contaminants from entering the bearing and reduce grease leakage; the lubricating holes are convenient for grease filling, which extends the service life and reduces the cost of maintenance and replacement.
4. Personalized design
For different occasions, the QIBR crossed cylindrical roller slewing bearing RKS 160 series can provide personalized size solutions to meet special applications. This not only enriches the bearing standards, but also provides effective guidance for manufacturers to meet the personalized needs of users.
In short, by optimizing manufacturing accuracy, personalized design and other measures, the performance of the QIBR crossed cylindrical roller slewing bearing RKS 160 series can be significantly improved to meet the increasingly demanding application requirements.
Main application areas of QIBR crossed cylindrical roller slewing bearing RKS 160 series
Machine tools
QIBR crossed cylindrical roller slewing bearing RKS 160 series ensures high-precision rotation stability in the turntable system of CNC machine tools.
Medical equipment: QIBR crossed cylindrical roller slewing bearing RKS 160 series is used in imaging equipment such as CT and operating tables to ensure smooth operation and high-precision positioning.
Heavy equipment: QIBR crossed cylindrical roller slewing bearing RKS 160 series provides strong support and anti-overturning ability in mining machinery, cranes and construction equipment.
Shipping and offshore engineering: QIBR crossed cylindrical roller slewing bearing RKS 160 series is used in ship's rotating devices and offshore platforms to withstand loads in harsh environments.
