Mast Guide Roller Bearings
Parts in bearing mechanical equipment
Application : Forklift
Alternative Brands : NTN
Subseries :
-
Mast Guide Roller Bearings
Specifications :
-
Outer Diameter : 2.5630 in.-7.9600 in.
-
Inner Diameter : 0.9843 in.-2.3622 in.
-
Overall Width : 0.5680 in.-1.8430 in.
QIBR
Model Selection
| NO. | Product | Product Number | Bore diameter (d) | Outside diameter (D) | Inner Ring (W2) | Outer Ring (W1) | Radius (R) |
|---|---|---|---|---|---|---|---|
| 102 |
|
MG-207-FFB | 1.3780 in. | 3.4800 in. | 0.6693 in. | 1.2550 in. | 0.0625 in. |
| 103 |
|
MG-307-FFB | 1.3780 in. | 3.9800 in. | 0.8268 in. | 1.2550 in. | 0.1250 in. |
| 104 |
|
MG-209-DD | 1.7717 in. | 3.9750 in. | 0.7480 in. | 1.1210 in. | 0.1250 in. |
| 105 |
|
MG-209-DD | 1.7717 in. | 4.7500 in. | 0.9843 in. | 1.2500 in. | 0.1250 in. |
| 106 |
|
MG-207-FFA | 1.3780 in. | 3.2230 in. | 0.6743 in. | 1.0670 in. | 0.1250 in. |
| 107 |
|
MG-5211-VFFB | 2.1654 in. | 5.9800 in. | 1.3810 in. | 1.8850 in. | 0.0600 in. |
| 108 |
|
MG-5311-VFFA | 2.1654 in. | 6.4400 in. | 1.9375 in. | 2.0670 in. | 0.4370 in. |
| 109 |
|
MG-5311-VZZA | 2.1654 in. | 6.4400 in. | 1.9375 in. | 2.0670 in. | 0.4370 in. |
| 110 |
|
MG-5208-VFFP | 1.5748 in. | 4.9900 in. | 1.1850 in. | 1.6880 in. | 0.3100 in. |
| 111 |
|
MG-5208-VFFPA | 1.5748 in. | 5.0150 in. | 1.1850 in. | 1.6880 in. | 0.3100 in. |
| 112 |
|
MG-5208-VFFPB | 1.5748 in. | 5.0450 in. | 1.1850 in. | 1.6880 in. | 0.3100 in. |
| 113 |
|
MG-5208-VFFQ | 1.5748 in. | 4.0770 in. | 1.1850 in. | 1.6880 in. | 0.3100 in. |
| 114 |
|
MG-5208-VFFQA | 1.5748 in. | 4.1070 in. | 1.1850 in. | 1.6880 in. | 0.3100 in. |
| 115 |
|
MG-5208-VFFQB | 1.5748 in. | 4.1360 in. | 1.1850 in. | 1.6880 in. | 0.3100 in. |
| 116 |
|
MG-5208-FFA | 1.5748 in. | 4.0820 in. | 1.1925 in. | 1.7600 in. | - |
| 117 |
|
MG-5208-VFF | 1.5748 in. | 4.0820 in. | 1.1925 in. | 1.7600 in. | - |
| 118 |
|
MG-5208-VFFA | 1.5748 in. | 4.0820 in. | 1.1925 in. | 1.6980 in. | - |
| 119 |
|
MG-5208-VFFE | 1.5748 in. | 4.9900 in. | 1.1925 in. | 1.6980 in. | - |
| 120 |
|
MG-5210-VFF | 1.9685 in. | 6.4500 in. | 1.1850 in. | 1.6900 in. | 0.1000 in. |
| 121 |
|
MG-5211-VFF | 2.1654 in. | 7.4600 in. | 1.5160 in. | 1.8100 in. | 0.1000 in. |
| 122 |
|
MG-5211-VFFA | 2.1654 in. | 6.2700 in. | 1.5180 in. | 1.8850 in. | 0.0600 in. |
| 123 |
|
MG-5211-VR | 2.1654 in. | 5.3850 in. | 1.5180 in. | 1.8850 in. | 0.0600 in. |
| 124 |
|
MG-5212-VZZ | 2.3622 in. | 7.4600 in. | 1.4375 in. | 2.1300 in. | 0.2500 in. |
| 125 |
|
MG-5212-VZZA | 2.3622 in. | 7.9600 in. | 1.4375 in. | 2.1300 in. | 0.2500 in. |
| 126 |
|
MG-5213-VFF | 2.5591 in. | 7.4120 in. | 1.8430 in. | 2.0600 in. | 0.0600 in. |
