Stainless Steel Deep Groove Ball Bearing
Stainless steel deep groove ball bearings are a type of bearing designed for applications where corrosion resistance and hygiene are essential. They are constructed using stainless steel for both the inner and outer rings, as well as the balls and often the cage.
Here's a brief description of their features and applications:
Corrosion Resistance: Stainless steel bearings are highly resistant to corrosion from moisture, chemicals, and other environmental factors. This makes them ideal for use in industries such as food and beverage, medical equipment, marine, and outdoor applications where exposure to harsh conditions is common.
Hygiene: Stainless steel is non-reactive and easy to clean, making these bearings suitable for applications requiring strict hygiene standards, such as food processing and pharmaceutical manufacturing.
High Temperature Resistance: Stainless steel bearings can withstand higher temperatures compared to standard bearings, making them suitable for applications where heat resistance is required.
Low Maintenance: Due to their corrosion resistance, stainless steel bearings require minimal maintenance, resulting in reduced downtime and lower overall operating costs.
Versatility: Stainless steel deep groove ball bearings are available in various sizes and configurations, allowing them to be used in a wide range of applications, including pumps, motors, conveyors, and agricultural equipment.
QIBR
Model Selection
NO. | Product | Product Number | Outer Diameter (D) | Inner Diameter (d) | Width (B) | Basic dynamic load rating (C) | Basic static load rating(Co) | Mass(g) |
---|---|---|---|---|---|---|---|---|
100 | 61901 2RS1 | 24mm | 12mm | 6mm | 2.51kN | 1.46kN | 10.5g | |
101 | 61901 2Z | 24mm | 12mm | 6mm | 2.51kN | 1.46kN | 11g | |
102 | 61901 | 24mm | 12mm | 6mm | 2.51kN | 1.46kN | 9.8g | |
103 | 6001 2RS1 | 28mm | 12mm | 8mm | 4.42kN | 2.36kN | 20g | |
104 | 6001 2Z | 28mm | 12mm | 8mm | 4.42kN | 2.36kN | 20g | |
105 | 6001 | 28mm | 12mm | 8mm | 4.42kN | 2.36kN | 20g | |
106 | 6201 2RS1 | 32mm | 12mm | 10mm | 5.72kN | 3kN | 36g | |
107 | 6201 2Z | 32mm | 12mm | 10mm | 5.72kN | 3kN | 0.6g | |
108 | 6201 | 32mm | 10mm | 5.72mm | 3kN | 0.127kN | 33.5g | |
109 | 6301 2RS1 | 37mm | 12mm | 12mm | 8.32kN | 4.15kN | 58.5g | |
110 | 6301 2Z | 37mm | 12mm | 12mm | 8.32kN | 4.15kN | 59.5g | |
111 | 6301 | 37mm | 12mm | 12mm | 8.32kN | 4.15kN | 55.5g | |
112 | 61802 2RS1 | 24mm | 15mm | 5mm | 1.65kN | 1.08kN | 7.1g | |
113 | 61802 2Z | 24mm | 15mm | 5mm | 1.65kN | 1.08kN | 6.7g | |
114 | 61902 2RS1 | 28mm | 15mm | 7mm | 3.71kN | 2.24kN | 16g | |
115 | 61902 2Z | 28mm | 15mm | 7mm | 3.71kN | 2.24kN | 16g | |
116 | 61902 | 28mm | 15mm | 7mm | 3.71kN | 2.24kN | 14.5g | |
117 | 6002 2RS1 | 32mm | 15mm | 9mm | 4.48kN | 2.8kN | 28.5g | |
118 | 6002 2Z | 32mm | 15mm | 9mm | 4.88kN | 2.8kN | 29g | |
119 | 6002 | 32mm | 15mm | 9mm | 4.88kN | 2.8kN | 26.5g | |
120 | 6202 2RS1 | 35mm | 15mm | 11mm | 6.37kN | 3.6kN | 44g | |
121 | 6002 2Z | 35mm | 15mm | 11mm | 6.37kN | 3.6kN | 44g | |
122 | 6202 | 35mm | 15mm | 11mm | 6.37kN | 3.6kN | 41.5g | |
123 | 6302 2RS1 | 42mm | 15mm | 13mm | 9.95kN | 5.4kN | 81g | |
124 | 6302 2Z | 42mm | 15mm | 13mm | 9.95kN | 5.4kN | 82g | |
125 | 6302 | 42mm | 15mm | 13mm | 9.95kN | 5.4kN | 77g | |
126 | 61803 2RS1 | 26mm | 17mm | 5mm | 1.78kN | 1.27kN | 8g | |
127 | 61803 2Z | 26mm | 17mm | 5mm | 1.78kN | 1.27kN | 7.6g | |
128 | 61903 2RS1 | 30mm | 17mm | 7mm | 3.97kN | 2.55kN | 16.5g | |
129 | 61903 2Z | 30mm | 17mm | 7mm | 3.97kN | 12.55kN | 17g | |
130 | 61903 | 30mm | 17mm | 7mm | 3.97kN | 2.55kN | 15.5g | |
131 | 6003 2RS1 | 35mm | 17mm | 10mm | 4.94kN | 3.15kN | 38g | |
132 | 6003 2Z | 35mm | 17mm | 10mm | 4.94kN | 3.15kN | 38.5g | |
133 | 6003 | 35mm | 17mm | 10mm | 4.94kN | 3.15kN | 36g | |
134 | 6203 2RS1 | 40mm | 17mm | 12mm | 8.06kN | 4.75kN | 64.5g | |
135 | 6203 2Z | 40mm | 17mm | 12mm | 8.06kN | 4.75kN | 65.5g | |
136 | 6203 | 40mm | 17mm | 12mm | 8.06kN | 4.75kN | 61.5g | |
137 | 6303 2RS1 | 47mm | 17mm | 14mm | 11.7kN | 6.55kN | 112g | |
138 | 6303 2Z | 47mm | 17mm | 14mm | 11.7kN | 6.55kN | 113g | |
139 | 6303 | 47mm | 17mm | 14mm | 11.7kN | 6.55kN | 107g | |
140 | 61804 2RS1 | 32mm | 20mm | 7mm | 3.12kN | 2.08kN | 17g | |
141 | 61804 2Z | 32mm | 20mm | 7mm | 3.12kN | 2.08kN | 17g | |
143 | 61904 2RS1 | 37mm | 20mm | 9mm | 5.53kN | 3.65kN | 35.5g | |
144 | 61904 | 37mm | 20mm | 9mm | 5.53kN | 3.65kN | 32.5g | |
145 | 6004 2RS1 | 42mm | 20mm | 12mm | 8.06kN | 5kN | 64.5g | |
146 | 6004 2Z | 42mm | 20mm | 12mm | 8.06kN | 5kN | 64.5g | |
147 | 6004 | 42mm | 20mm | 12mm | 8.06kN | 5kN | 60.5g | |
148 | 6204 2RS1 | 42mm | 20mm | 14mm | 10.8kN | 6.55kN | 105g | |
149 | 6204 2Z | 47mm | 20mm | 14mm | 10.8kN | 6.55kN | 144g | |
150 | 6204 | 47mm | 20mm | 14mm | 10.8kN | 6.55kN | 100g | |
151 | 6304 2RS1 | 52mm | 20mm | 15mm | 13.8kN | 7.8kN | 143g | |
152 | 6304 2Z | 52mm | 20mm | 15mm | 13.8kN | 7.8kN | 144g | |
153 | 6304 | 52mm | 20mm | 15mm | 13.8kN | 7.8kN | 136g | |
154 | 61805 2RS1 | 37mm | 25mm | 7mm | 3.38kN | 2.5kN | 21g | |
155 | 61805 2Z | 37mm | 25mm | 7mm | 3.38kN | 2.5kN | 21g | |
156 | 61905 2RS1 | 42mm | 25mm | 9mm | 6.05kN | 4.5kN | 39.5g | |
157 | 6005 2RS1 | 47mm | 25mm | 12mm | 8.71kN | 6.85kN | 76.5g | |
158 | 6005 2Z | 47mm | 25mm | 12mm | 8.71kN | 5.85kN | 77.5g | |
159 | 6005 | 47mm | 25mm | 12mm | 8.71kN | 5.85kN | 71.5g | |
160 | 6205 2RS1 | 52mm | 25mm | 15mm | 11.7kN | 7.65kN | 76.5g | |
161 | 6205 2Z | 52mm | 25mm | 15mm | 11.7kN | 7.65kN | 130g | |
162 | 6205 | 52mm | 25mm | 15mm | 11.7kN | 7.65kN | 122g | |
163 | 6305 2RS1 | 62mm | 25mm | 17mm | 17.8kN | 11.2kN | 234g | |
164 | 6305 2Z | 62mm | 25mm | 17mm | 17.8kN | 11.2kN | 235g | |
165 | 6305 | 62mm | 25mm | 17mm | 17.8kN | 11.2kN | 224g | |
166 | 61806 2RS1 | 42mm | 30mm | 7mm | 3.58kN | 2.9kN | 24g | |
167 | 61906 2RS1 | 47mm | 30mm | 9mm | 6.24kN | 5kN | 24g | |
168 | 61906 | 47mm | 30mm | 9mm | 6.24kN | 5kN | 43.5g | |
169 | 6006 2RS1 | 55mm | 30mm | 13mm | 11.4kN | 8.15kN | 24g | |
170 | 6006 2Z | 55mm | 30mm | 13mm | 11.4kN | 8.15kN | 113g | |
171 | 6006 | 55mm | 30mm | 13mm | 11.4kN | 8.15kN | 105g | |
172 | 6206 2RS1 | 62mm | 30mm | 16mm | 16.5kN | 11.2kN | 196g | |
173 | 6206 2Z | 62mm | 30mm | 16mm | 16.5kN | 11.2kN | 196g | |
174 | 6206 | 62mm | 30mm | 16mm | 16.5kN | 11.2kN | 186g | |
175 | 6306 2RS1 | 72mm | 30mm | 19mm | 22.9kN | 15kN | 346g | |
180 | 6306 2Z | 72mm | 30mm | 19mm | 22.9kN | 15kN | 345g | |
181 | 6306 | 72mm | 30mm | 19mm | 22.9kN | 15kN | 331g | |
182 | 61807 2RS1 | 47mm | 35mm | 7mm | 3.71kN | 3.35kN | 29.5g | |
183 | 61907 2RS1 | 55mm | 35mm | 10mm | 9.36kN | 7.65kN | 73.5g | |
184 | 6007 2RS1 | 62mm | 35mm | 14mm | 13.8kN | 10.2kN | 147g | |
185 | 6007 2Z | 62mm | 35mm | 14mm | 13.8kN | 10.2kN | 148g | |
186 | 6007 | 62mm | 35mm | 14mm | 13.8kN | 10.2kN | 138g | |
187 | 6207 2RS1 | 72mm | 35mm | 17mm | 22.1kN | 15.3kN | 276g | |
188 | 6207 2Z | 72mm | 35mm | 17mm | 22.1kN | 15.3kN | 277g | |
189 | 6207 | 72mm | 35mm | 17mm | 22.1kN | 15.3kN | 262g | |
190 | 6307 2RS1 | 80mm | 35mm | 21mm | 28.6kN | 19kN | 441g | |
191 | 61908 2RS1 | 62mm | 40mm | 12mm | 11.9kN | 9.8kN | 107g | |
192 | 6008 2RS1 | 68mm | 40mm | 15mm | 14.6kN | 11.4kN | 182g | |
193 | 6008 2Z | 68mm | 40mm | 15mm | 14.6kN | 11.4kN | 183g | |
194 | 6008 | 68mm | 40mm | 15mm | 14.6kN | 11.4kN | 172g | |
195 | 6208 2RS1 | 80mm | 40mm | 18mm | 25.1kN | 17.6kN | 359g | |
196 | 6208 2Z | 80mm | 40mm | 18mm | 25.1kN | 17.6kN | 183g | |
197 | 6208 | 80mm | 40mm | 18mm | 25.1kN | 17.6kN | 342g | |
198 | 6009 2RS1 | 75mm | 45mm | 16mm | 18.2kN | 15kN | 236g | |
199 | 6009 2Z | 75mm | 45mm | 16mm | 18.2kN | 15kN | 237g | |
200 | 6209 2RS1 | 85mm | 45mm | 19mm | 28.1kN | 20.4kN | 395g | |
201 | 6209 2Z | 85mm | 45mm | 19mm | 28.1kN | 20.4kN | 374g | |
202 | 6010 2RS1 | 80mm | 50mm | 16mm | 19kN | 16.6kN | 256g | |
203 | 6010 2Z | 80mm | 50mm | 16mm | 19kN | 16.6kN | 256g | |
204 | 6210 2RS1 | 90mm | 50mm | 20mm | 30.2kN | 23.2kN | 449g |
