Изображения могут отличаться от продукта. Подробнее см. технические характеристики.
Стандарт
GB,ASTM/AISI,ГОСТ,BS,JIS,NF,DIN/VDEh,DIN/VDEh
Внутренний диаметр
120mm-8000mm
Наружный диаметр
280mm-8000mm
Вес
20kg-8000kg
Structures
Outer Ring, Inner Ring, Spacer, Rolling element, Seal
Бренд
QIBR/OEM/Neutral
Упаковка
Standard Export Package
Материал
42CrMo, 50Mn, or Stainless Steel
Применения
Hoisting machinery, construction machinery, material handling machinery, mining machinery, metallurgical machinery, medical instruments,ships and warships, radar,wind turbine

NO. | Product | Product Number | Внутренний диаметр (d) | Наружный диаметр (D) | Диаметр дорожки качения (dm) | Вес | Тип шестерни |
---|---|---|---|---|---|---|---|
1 |
![]() |
RKS.161.14.0414 | 344 mm | 504 mm | 414 mm | 32 kg | External gear |
2 |
![]() |
RKS.161.14.0544 | 474 mm | 640.8 mm | 544 mm | 44 kg | External gear |
3 |
![]() |
RKS.161.14.0644 | 574 mm | 742.8 mm | 644 mm | 52 kg | External gear |
4 |
![]() |
RKS.161.14.0744 | 674 mm | 838.8 mm | 744 mm | 59 kg | External gear |
5 |
![]() |
RKS.161.14.0844 | 774 mm | 950.4 mm | 844 mm | 71 kg | External gear |
6 |
![]() |
RKS.161.14.0944 | 874 mm | 1046.4 mm | 944 mm | 77 kg | External gear |
7 |
![]() |
RKS.161.14.1094 | 1024 mm | 1198.4 mm | 1094 mm | 91 kg | External gear |
8 |
![]() |
RKS.161.16.1204 | 1119 mm | 1338 mm | 1204 mm | 155 kg | External gear |
9 |
![]() |
RKS.161.16.1314 | 1229 mm | 1448 mm | 1314 mm | 168 kg | External gear |
10 |
![]() |
RKS.161.16.1424 | 1339 mm | 1558 mm | 1424 mm | 182 kg | External gear |
11 |
![]() |
RKS.161.16.1534 | 1449 mm | 1668 mm | 1534 mm | 195 kg | External gear |
12 |
![]() |
RKS.161.16.1644 | 1536 mm | 1791 mm | 1644 mm | 242 kg | External gear |
13 |
![]() |
RKS.161.16.1754 | 1646 mm | 1901 mm | 1754 mm | 258 kg | External gear |
14 |
![]() |
RKS.161.20.1904 | 1796 mm | 2073.4 mm | 1904 mm | 305 kg | External gear |
Features and advantages of QIBR crossed cylindrical roller slewing bearing RKS 161 series
QIBR crossed cylindrical roller slewing bearing RKS 161 series has several significant features and advantages, playing a key role in various fields, mainly reflected in the following aspects:
1.QIBR crossed cylindrical roller slewing bearing RKS 161 series has high load-bearing capacity
The QIBR crossed cylindrical roller slewing bearing RKS 161 series design allows the bearing to carry radial and axial loads in multiple directions at the same time, and is suitable for withstanding heavy loads and impact loads.
2.QIBR crossed cylindrical roller slewing bearing RKS 161 series has good stability and long life
QIBR crossed cylindrical roller slewing bearing RKS 161 series has high manufacturing precision and small assembly clearance. The bearing has high working stability, reduces system vibration and noise, improves the smoothness and reliability of operation, thereby extending the service life of the bearing. .
3. The customized services of QIBR crossed cylindrical roller slewing bearing RKS 161 series
QIBR crossed cylindrical roller slewing bearing RKS 161 series can provide customized services and can design bearings according to specific needs to meet the special requirements and operating conditions of different industries.
4.QIBR crossed cylindrical roller slewing bearing RKS 161 series has efficient transmission capability
The design of external teeth of QIBR crossed cylindrical roller slewing bearings RKS 161 series allows direct connection with gear drive systems, resulting in efficient power transmission. This eliminates the need for additional transmission components such as chains or belts, reducing mechanical wear and maintenance requirements.
The performance improvement and solutions of QIBR crossed cylindrical roller slewing bearing RKS 161 series
1. Improve material performance of the bearing
QIBR Crossed Cylindrical Roller Turntable Bearing RKS 161 Series can use materials such as high-temperature sealing strips to improve the bearing capacity and service life.
2. Improve rotation accuracy of the bearing
The production of QIBR Crossed Cylindrical Roller Turntable Bearing RKS 161 Series adopts advanced processing equipment and processes, such as machining centers and precision heat treatment, to improve the geometric accuracy of the inner and outer rings, reduce machining errors, and thus improve the bearing rotation accuracy and stability.
3. Reduce the need for bearing maintenance and replacement
QIBR Crossed Cylindrical Roller Turntable Bearing RKS 161 Series is designed with seals and lubricating oil holes. The seals can prevent contaminants from entering the bearing and reduce grease leakage; the lubricating holes are convenient for grease filling, which prolongs the service life and reduces the cost of maintenance and replacement.
4. Personalized design
For different occasions, the QIBR Crossed Cylindrical Roller Turntable Bearing RKS 161 Series can provide personalized size solutions to meet special applications. This not only enriches the standards of bearings, but also provides effective guidance for manufacturers to meet the personalized needs of users.
In short, by optimizing materials, manufacturing accuracy, personalized design and other measures, the performance of QIBR cross cylindrical roller slewing bearing RKS 161 series can be significantly improved to meet the increasingly demanding application requirements.
Main application areas of QIBR crossed cylindrical roller slewing bearing RKS 161 series
Machine tools
QIBR crossed cylindrical roller slewing bearing RKS 161 series ensures high-precision rotation stability in the turntable system of CNC machine tools.
Medical equipment: QIBR crossed cylindrical roller slewing bearing RKS 161 series is used in imaging equipment such as CT and operating tables to ensure smooth operation and high-precision positioning.
Heavy equipment: QIBR crossed cylindrical roller slewing bearing RKS 161 series provides strong support and anti-overturning ability in mining machinery, cranes and construction equipment.
Shipping and offshore engineering: QIBR crossed cylindrical roller slewing bearing RKS 161 series is used in ship's rotating devices and offshore platforms to withstand loads in harsh environments.
