GB 3038

GB 3038 GB30 and GB10 Internal Clearance Gauge Product Features and Advantages

High Accuracy: Capable of precisely measuring the outer envelope diameter of the roller set.

High Precision: For sizes ≤ 20 (GB 3006 to GB 3020 and GB 1010 to GB 1020), the measurement precision is less than 1 μm; for sizes ≥ 21 (GB 3021 to GB 3068), it is less than 2 μm.

User-Friendly: The gauge is designed for ease of use, making it convenient to operate.

Wide Applicability: Suitable for measuring various models of cylindrical roller bearings, meeting diverse application needs.

Application: Primarily used to measure the internal clearance of cylindrical roller bearings, widely applied in mechanical manufacturing, medical devices, power equipment, automotive industry, and aerospace sectors.

QIBR - GB 3038 GB30 and GB10 Internal Clearance Gauge Optimization

Structural Selection: Depending on the measurement size, gauges can be selected from two-piece or slotted types.

Surface Treatment: The gauge surface can be specially treated based on customer needs and working environment, such as chrome plating or titanium nitriding.

More customization: QIBR can optimize and customize the gauge's accuracy and dimensions according to customer requirements.

QIBR - GB 3038 GB30 and GB10 Internal Clearance Gauge Quality Control

Dimension measurement: Utilizes various professional high-precision instruments to measure multiple dimensions of the GB30 and GB10 gauges, achieving a maximum precision of 0.001 mm.

Hardness measurement: Surface hardness of the GB30 and GB10 gauges is measured using a hardness tester, with a measurement accuracy of ±0.5 HRC.

Metallographic Analysis: Conducts analysis of the internal metallographic structure using specialized metallographic microscopes.

Raw material control: Steel and components are sourced from ISO 14001 certified suppliers, ensuring product stability while promoting sustainable development.
