Double row full complement cylindrical roller bearings without outer ring

Изображения могут отличаться от продукта. Подробнее см. технические характеристики.

Стандарт

GB,ASTM/AISI,ГОСТ,BS,JIS,NF,DIN / VDEh

Материал

GCr15/ 100Cr6/ Bearing Steel

Диаметр внутреннего кольца

18-140mm

Диаметр наружного кольца

32.3-197.82mm

Вес

-

Бренд

QIBR/OEM/Neutral

Упаковка

QIBR/Standard Industrial Package/OEM

Применения

gearboxes, machine tools, and heavy machinery, etc

Double row full complement cylindrical roller bearings without outer ring

Filters

NO. Product Product Number Отверстие Внешняя окружность оболочки (Dr) Ширина (B) ширина дорожки качения (X)
1 CPM2699/ CPM2699 18 mm 32.3 mm 20.5 mm 14.9 mm
2 CPM2435/ CPM2435 22 mm 36.2 mm 30 mm 23 mm
3 CPM2535/ CPM2535 22 mm 38.75 mm 22.5 mm 17.3 mm
4 CPM2400/ CPM2400 24 mm 40.25 mm 26 mm 20 mm
5 CPM2597/ CPM2597 24 mm 40.25 mm 34 mm 24 mm
6 CPM2686/ CPM2686 25 mm 40.25 mm 26 mm 20 mm
7 CPM2613/ CPM2613 25 mm 40.25 mm 32 mm 24 mm
8 CPM2519/ CPM2519 28 mm 43.35 mm 26.5 mm 20 mm
9 CPM2776/ CPM2776 28 mm 44.45 mm 34 mm 27.6 mm
10 CPM2594/ CPM2594 30 mm 46.4 mm 32 mm 27.6 mm
11 CPM2687/ CPM2687 30 mm 48.25 mm 40 mm 32 mm
12 CPM2510/ CPM2510 30 mm 49.6 mm 26 mm 20 mm
13 CPM2178/ CPM2178 30 mm 49.6 mm 24 mm 18 mm
14 CPM2651/ CPM2651 30 mm 49.6 mm 25 mm 18.9 mm
15 CPM2198/ CPM2198 30 mm 49.6 mm 26 mm 20 mm
16 CPM2683/ CPM2683 30 mm 49.6 mm 30 mm 24 mm
17 CPM2508/ CPM2508 32 mm 46.6 mm 25 mm 20.5 mm
18 CPM2183-2439/ CPM2183-2439 32 mm 46.6 mm 28 mm 22 mm
19 CPM2668/ CPM2668 32 mm 48.24 mm 34 mm 27.6 mm
20 CPM2496/ CPM2496 32 mm 51.75 mm 25 mm 19.9 mm
21 CPM2579/ CPM2579 32 mm 51.75 mm 29 mm 24 mm
22 CPM2634/ CPM2634 34 mm 50.2 mm 29 mm 23.6 mm
23 CPM2434/ CPM2434 35 mm 49.8 mm 28 mm 22 mm
24 CPM2488-2723/ CPM2488-2723 35 mm 52.09 mm 26.5 mm 20.9 mm
25 CPM2470/ CPM2470 35 mm 55.52 mm 36 mm 28 mm
26 CPM2520/ CPM2520 35 mm 55.52 mm 36 mm 28 mm
27 CPM2706/ CPM2706 35 mm 55.52 mm 36 mm 28 mm
28 CPM2721/ CPM2721 35 mm 59.19 mm 27 mm 21.33 mm
29 CPM2528/ CPM2528 35 mm 64.3 mm 26.5 mm 20.9 mm
30 CPM2164/ CPM2164 38 mm 55.95 mm 28 mm 22 mm
31 CPM2504/ CPM2504 38 mm 52.95 mm 29.5 mm 21.9 mm
32 CPM2806/ CPM2806 38 mm 52.95 mm 29.5 mm 21.9 mm
33 CPM2464/ CPM2464 38 mm 54.69 mm 29.5 mm 20.7 mm
34 CPM2458/ CPM2458 38 mm 54.69 mm 29.5 mm 21.6 mm
35 CPM2669/ CPM2669 38 mm 57.91 mm 38 mm 32 mm
36 CPM2168/ CPM2168 40 mm 57.81 mm 34 mm 28 mm
37 CPM2729/ CPM2729 40 mm 60.68 mm 31 mm 25.6 mm
38 CPM2179/ CPM2179 40 mm 61.74 mm 28 mm 20.9 mm
39 CPM2188/ CPM2188 40 mm 61.74 mm 28 mm 20.9 mm
40 CPM2180/ CPM2180 40 mm 61.74 mm 32 mm 24.9 mm
41 CPM2650/ CPM2650 40 mm 61.74 mm 35.5 mm 27.6 mm
42 CPM2506/ CPM2506 40 mm 61.74 mm 38 mm 30.0 mm
43 CPM2567/ CPM2567 40 mm 75.63 mm 78 mm 61.1 mm
44 CPM2412/ CPM2412 42 mm 60.75 mm 37 mm 30.9 mm
45 CPM2777/ CPM2777 42 mm 60.75 mm 37 mm 31.6 mm
46 CPM2592/ CPM2592 44 mm 61.6 mm 34 mm 28 mm
47 CPM2401/ CPM2401 44 mm 62.97 mm 37 mm 30.9 mm
48 CPM2559/ CPM2559 45 mm 61.55 mm 32 mm 24.9 mm
49 CPM2425/ CPM2425 45 mm 61.55 mm 36 mm 28.9 mm
50 CPM2647/ CPM2647 45 mm 65.02 mm 34 mm 27.3 mm
51 CPM2419-2722/ CPM2419-2722 45 mm 66.85 mm 37.5 mm 28.6 mm
52 CPM2619/ CPM2619 45 mm 83.88 mm 85 mm 64.7 mm
53 CPM2807/ CPM2807 46 mm 69.5 mm 45 mm 37.3 mm
54 CPM2530/ CPM2530 50 mm 67.28 mm 32 mm 25.8 mm
55 CPM2720/ CPM2720 50 mm 67.36 mm 40 mm 32.6 mm
56 CPM2719/ CPM2719 50 mm 69.58 mm 40 mm 33.3 mm
57 CPM2492/ CPM2492 50 mm 69.67 mm 32 mm 24.9 mm
58 CPM2609/ CPM2609 50 mm 69.67 mm 37.5 mm 31.4 mm
59 CPM2590/ CPM2590 50 mm 69.67 mm 42.5 mm 33.4 mm
60 CPM2645/ CPM2645 50 mm 72 mm 31 mm 24 mm
61 CPM2466/ CPM2466 50 mm 72.05 mm 37 mm 28.5 mm
62 CPM2518/ CPM2518 50 mm 72.33 mm 39 mm 32.5 mm
63 CPM2190-2465/ CPM2190-2465 50 mm 72.33 mm 40 mm 33.1 mm
64 CPM2432-2596/ CPM2432-2596 50 mm 72.33 mm 40 mm 33.1 mm
65 CPM2649/ CPM2649 50 mm 75.25 mm 40 mm 32.5 mm
66 CPM2798/ CPM2798 50 mm 81.45 mm 32 mm 26.1 mm
67 CPM2698/ CPM2698 55 mm 76.94 mm 40 mm 31.1 mm
68 CPM2593/ CPM2593 55 mm 77.07 mm 41 mm 33.8 mm
69 CPM2191-2444/ CPM2191-2444 55 mm 83.54 mm 46 mm 39 mm
70 CPM2509-2685/ CPM2509-2685 55 mm 83.54 mm 47 mm 40.1 mm
71 CPM2731/ CPM2731 55 mm 85.07 mm 41 mm 33.8 mm
72 CPM2620/ CPM2620 55 mm 94.76 mm 100 mm 76.7 mm
73 CPM2558-2674/ CPM2558-2674 55 mm 88.85 mm 52 mm 42.1 mm
74 CPM2532-2724/ CPM2532-2724 60 mm 83.83 mm 46 mm 39.8 mm
75 CPM2495-2566/ CPM2495-2566 60 mm 83.83 mm 47 mm 39.8 mm
76 CPM2799/ CPM2799 60 mm 89.8 mm 52 mm 42.6 mm
77 CPM2656/ CPM2656 65 mm 89.8 mm 48 mm 40.6 mm
78 CPM2652-2783/ CPM2652-2783 65 mm 93.09 mm 46 mm 39 mm
79 CPM2527/ CPM2527 65 mm 93.1 mm 58 mm 49.6 mm
80 CPM2617/ CPM2617 65 mm 109.66 mm 110 mm 83.7 mm
81 CPM2700-2702/ CPM2700-2702 70 mm 95.29 mm 54 mm 43.6 mm
82 CPM2507/ CPM2507 70 mm 100.28 mm 54 mm 42 mm
83 CPM2735/ CPM2735 75 mm 115.78 mm 31.2 mm 53 mm
84 CPM2640/ CPM2640 75 mm 127.55 mm 120 mm 90.6 mm
85 CPM2703/ CPM2703 80 mm 111.76 mm 62 mm 52 mm
86 CPM2610/ CPM2610 80 mm 112.75 mm 60 mm 50 mm
87 CPM2657/ CPM2657 80 mm 122.1 mm 70 mm 60 mm
88 CPM2641/ CPM2641 80 mm 141.92 mm 130 mm 100.6 mm
89 CPM2633/ CPM2633 85 mm 121.4 mm 70 mm 60 mm
90 CPM2682/ CPM2682 85 mm 121.4 mm 60 mm 49 mm
91 CPM2734/ CPM2734 90 mm 130.11 mm 72 mm 58.7 mm
92 CPM2642/ CPM2642 95 mm 155.87 mm 150 mm 118.6 mm
93 CPM2736/ CPM2736 110 mm 156.13 mm 80 mm 62 mm
94 CPM2655/ CPM2655 130 mm 183.81 mm 95 mm 78 mm
95 CPM2681/ CPM2681 140 mm 197.82 mm 95 mm 81 mm

Features and advantages of QIBR double row full complement cylindrical roller bearings without outer ring

QIBR double row full complement cylindrical roller bearings without outer ring solves several key problems in various fields, which are mainly reflected in the following aspects:

1. QIBR double row full complement cylindrical roller bearings without outer ring High rigidity

QIBR double row full complement cylindrical roller bearings without outer ring Due to the dense contact between the roller and the inner ring, the rigidity of this bearing is relatively strong, which can provide stable support and precise operation.

2. QIBR double row full complement cylindrical roller bearings without outer ring Compact design

QIBR double row full complement cylindrical roller bearings without outer ring adopts a full-fill design, with a large number of rollers and a relatively small radial size, which can be used in places with limited space.

3. QIBR double row full complement cylindrical roller bearings without outer ring has high load-bearing capacity

QIBR double row full complement cylindrical roller bearings without outer ring Each roller almost contacts the load surface, so this bearing has a very high load-bearing capacity, which is particularly suitable for applications with heavy loads.

4. QIBR double row full complement cylindrical roller bearings without outer ring save space

The characteristic of QIBR double row full complement cylindrical roller bearings without outer ring is that it does not use an outer ring, but bears the load through the contact between the roller and the inner ring. This design makes the bearing more suitable for some applications with limited space.

5. QIBR double row full complement cylindrical roller bearings without outer ring save energy

QIBR double row full complement cylindrical roller bearings without outer ring reduce the friction between the outer ring and the inner ring: the design of direct contact between the roller and the inner ring reduces the friction between the outer ring and the inner ring, further reducing energy loss.

The performance improvement and solution of QIBR double row full complement cylindrical roller bearings without outer ring

1. Improve corrosion resistance

For bearings that need to work in harsh environments, especially when used in humid, chemical media or salt spray environments, QIBR double row full complement cylindrical roller bearings without outer ring can use stainless steel or other corrosion-resistant materials, or perform special corrosion-resistant treatment on the bearing surface (such as electroplating, coating, etc.), thereby extending its service life.

2. Optimize rollers

QIBR double row full complement cylindrical roller bearings without outer ring can reduce contact stress, improve load capacity and durability by optimizing roller shape. Roller surface treatment can reduce friction, improve rolling accuracy and load capacity, and extend the service life of bearings.

3. Improve manufacturing accuracy

QIBR double row full complement cylindrical roller bearings without outer ring adopts advanced foreign processing equipment and processes, such as precision grinding, superfine grinding, etc., to improve the geometric accuracy of inner and outer rings and rollers, reduce processing errors, and thus improve the rotation accuracy and roughness of bearings.

4. Lubricant optimization

QIBR double row full complement cylindrical roller bearings without outer ring use high-performance lubricants (such as synthetic oil, solid lubricant, nano lubricant, etc.) to improve lubrication effect and reduce friction and wear. In high temperature environment, the choice of lubricant is particularly important, and high temperature and corrosion resistant lubricating oil or grease can be used.

Main application areas of QIBR double row full complement cylindrical roller bearings without outer ring

1. Mining machinery

Such as ball mills, crushers, vibrating screens and other equipment. These equipment will generate large radial loads during operation and have a harsh working environment. QIBR double row full complement cylindrical roller bearings without outer ring can effectively withstand such high loads and have high impact resistance.

2. Heavy machine tools

In high-precision heavy machine tools, QIBR double row full complement cylindrical roller bearings without outer ring are used to withstand heavy loads and ensure the processing accuracy and stability of the machine.

3. Precision gearbox

QIBR double row full complement cylindrical roller bearings without outer ring are suitable for occasions requiring high load capacity, but due to its design structure, it is still suitable for machines with high precision requirements.

4. Wind turbines

In important parts such as the main bearings and gearbox bearings of wind turbines, QIBR double row full complement cylindrical roller bearings without outer ring provide excellent load support capabilities. Especially in strong wind and high load working environments, it can ensure the long-term operation of wind power equipment.
