BNR 10&BER 10
The internal design and contact angle of this series of bearings ensure optimal load distribution and enhanced rigidity, making them ideal for applications with stringent high-precision requirements.
QIBR
Model Selection
| NO. | Product | Product Number | Outer Diameter (D) | Inner Diameter (d) | Width (B) | Basic static load rating(Cor) | Mass(M) | Basic Dynamic Load Rating(Cr) |
|---|---|---|---|---|---|---|---|---|
| 1 |
|
30BNR10S | 55mm | 30mm | 13mm | 5.75KN | 0.124kg | 8.65KN |
| 2 |
|
30BNR10H | 55mm | 30mm | 13mm | 5.75KN | 0.116kg | 8.65KN |
| 3 |
|
30BNR10X | 55mm | 30mm | 13mm | 5.75KN | 0.116kg | 8.65KN |
| 4 |
|
30BER10S | 55mm | 30mm | 13mm | 5.50KN | 0.124kg | 8.30KN |
| 5 |
|
30BER10H | 55mm | 30mm | 13mm | 5.50KN | 0.116kg | 8.30KN |
| 6 |
|
30BER10X | 55mm | 30mm | 13mm | 5.50KN | 0.116kg | 8.30KN |
| 7 |
|
35BNR10S | 62mm | 35mm | 14mm | 7.10KN | 0.164kg | 10.10KN |
| 8 |
|
35BNR10H | 62mm | 35mm | 14mm | 7.10KN | 0.154kg | 10.10KN |
| 9 |
|
35BNR10X | 62mm | 35mm | 14mm | 7.10KN | 0.154kg | 10.10KN |
| 10 |
|
35BER10S | 62mm | 35mm | 14mm | 6.85KN | 0.164kg | 9.70KN |
| 11 |
|
35BER10H | 62mm | 35mm | 14mm | 6.85KN | 0.154kg | 9.70KN |
| 12 |
|
35BER10X | 62mm | 35mm | 14mm | 6.85KN | 0.154kg | 9.70KN |
| 13 |
|
40BNR10S | 68mm | 40mm | 15mm | 7.95KN | 0.204kg | 10.60KN |
| 14 |
|
40BNR10H | 68mm | 40mm | 15mm | 7.95KN | 0.193kg | 10.60KN |
| 15 |
|
40BNR10X | 68mm | 40mm | 15mm | 7.95KN | 0.193kg | 10.60KN |
| 16 |
|
40BER10S | 68mm | 40mm | 15mm | 7.65KN | 0.204kg | 10.10KN |
| 17 |
|
40BER10H | 68mm | 40mm | 15mm | 7.65KN | 0.193kg | 10.10KN |
| 18 |
|
40BER10X | 68mm | 40mm | 15mm | 7.65KN | 0.193kg | 10.10KN |
| 19 |
|
45BNR10S | 75mm | 45mm | 16mm | 9.00KN | 0.259kg | 11.70KN |
| 20 |
|
45BNR10H | 75mm | 45mm | 16mm | 9.00KN | 0.246kg | 11.70KN |
| 21 |
|
45BNR10X | 75mm | 45mm | 16mm | 9.00KN | 0.246kg | 11.70KN |
| 22 |
|
45BER10S | 75mm | 45mm | 16mm | 8.60KN | 0.259kg | 11.20KN |
| 23 |
|
45BER10H | 75mm | 45mm | 16mm | 8.60KN | 0.246kg | 11.20KN |
| 24 |
|
45BER10X | 75mm | 45mm | 16mm | 8.60KN | 0.246kg | 11.20KN |
| 25 |
|
50BNR10S | 80mm | 50mm | 16mm | 9.90KN | 0.281kg | 12.20KN |
| 26 |
|
50BNR10H | 80mm | 50mm | 16mm | 9.90KN | 0.266kg | 12.20KN |
| 27 |
|
50BNR10X | 80mm | 50mm | 16mm | 9.90KN | 0.266kg | 12.20KN |
| 28 |
|
50BER10S | 80mm | 50mm | 16mm | 9.50KN | 0.281kg | 11.60KN |
| 29 |
|
50BER10H | 80mm | 50mm | 16mm | 9.50KN | 0.266kg | 11.60KN |
| 30 |
|
50BER10X | 80mm | 50mm | 16mm | 9.50KN | 0.266kg | 11.60KN |
